| Type | Rated input | Rated output | Accuracy (%)≤ | Voltage | Response time | Shape |
|---|
| CA1C-50..600A | 50..600Arms | 4Vrms | ±1 | ±15V | 3μs |
|
| CA1C-50..600A/SP1 | 50..600Arms | 4Vrms | ±1 | ±15V | 3μs |
|
| CA1C5-50..600A | 50..600Arms | 2.5±0.5V | ±2 | 5V | 5μs |
|
| CA1C5-50..600A/SP1 | 50..600Arms | 2.5±0.5V | ±2 | 5V | 5μs |
|
| CA1B-400..2000A | ±400..2000A | ±10V | ±1~±4 | ±15V | 15μs |
|
| CA1B4-400..2000A | ±400..2000A | 4~20mA | ±1~±4 | 24V | 100μs |
|
| ZDS-1000A | 1000A | -10V | ±1~±2 | ±15V | 15μs |
|
