| Type | Rated input | Rated output | Accuracy (%)≤ | Voltage | Response time | Shape |
|---|
| CV4A-50V | 50Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-125V | 125Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-150V | 150Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-250V | 250Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-500V | 500Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-750V | 750Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-1000V | 1000Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-1250V | 1250Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-1500V | 1500Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-2000V | 2000Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-50..2000V/SP2 | 50..2000Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
| CV4A-50..2000V/SP3 | 50..2000Vrms | 50mArms | ±0.7 | ±12~±24V | 10μs~13μs |
|
