| Type | Rated input | Rated output | Accuracy (%)≤ | Voltage | Response time | Shape |
|---|
| CV25-P | 10mArms | 25mArms | ±0.8 | ±15V | 40μs |
|
| CV25-50~600V | 50~600Vrms | 25mArms | ±0.8 | ±12V~±15V | 15μs |
|
| CV25-700~1200V | 700~1200Vrms | 25mArms | ±0.8 | ±12V~±15V | 40μs |
|
| CV100-50V | 50Vrms | 50mArms | ±1 | ±15~±24V | 40μs |
|
| CV100-100V | 100Vrms | 50mArms | ±1 | ±15~±24V | 50μs |
|
| CV100-200V | 200Vrms | 50mArms | ±1 | ±15~±24V | 60μs |
|
| CV100-400V | 400Vrms | 50mArms | ±1 | ±15~±24V | 80μs |
|
| CV100-500V | 500Vrms | 50mArms | ±1 | ±15~±24V | 80μs |
|
| CV100-800V | 800Vrms | 50mArms | ±1 | ±15~±24V | 100μs |
|
| CV100-1000V | 1000Vrms | 50mArms | ±1 | ±15~±24V | 120μs |
|
| CV100-1500V | 1500Vrms | 40mArms | ±1 | ±15~±24V | 120μs |
|
| CV100-2000V | 2000Vrms | 40mArms | ±1 | ±15~±24V | 120μs |
|
| CV100-2500V | 2500Vrms | 40mArms | ±1 | ±15~±24V | 120μs |
|
| CV100-()V/SP1 | (50~1000)Vrms | 40mArms | ±1 | ±15~±24V | 40μs～120μs |
|
| CV100-1000V/SP4 | 1000Vrms | 50mArms | ±1 | ±15~±24V | 70μs |
|
| CV100-2000V/SP4 | 2000Vrms | 40mArms | ±1 | ±15~±24V | 100μs |
|
| CV100-1000~2000V/SP5 | 1000~2000Vrms | 50mArms | ±0.7 | ±15~±24V | 65μs~75μs |
|
| CV100-1000~2000V/SP6 | 1000~2000Vrms | 50mArms | ±0.7 | ±15~±24V | 50μs～60μs |
|
| CV100-1000~4000V/SP7 | 1000~4000Vrms | 50mArms | ±0.7 | ±15~±24V | 50μs～200μs |
|
| CV100-AW | 10mArms | 50mArms | ±0.7 | ±12~±24V | 20μs～100μs |
|
