The product complies with GB/T 21413.1 "Railway Application Electrical Equipment for Locomotives and Vehicles Part 1: General Conditions of Use and General Rules" and GB/T 21413.2 "Railway Applications Electrical Equipment for Locomotives and Vehicles Part 2: General Rules for Electrical Equipment".
Product parameters
Contact type: S826 series quick switch
Potentiometer: FSG PW70
Protection level: IP00
Pollution degree: PD3
Overvoltage level: OV3
Life expectancy: 2 million mechanical life, 200,000 electrical life
Weight: about 13Kg
Handle operating force: can be customized according to user requirements
Connector connection: the connector can be executed according to user requirements
Contact connection: M3 screw
Applicable models: Shanghai Metro Line 1, Athens Metro
Features
