Bearing Tpye |
Dimensions（mm） |
Rated load（kN） |
Weight(kg) |
|
||||||||||||
|
Fw |
Ew |
B |
Cr |
Cor |
||||||||||||
|
KNL 25×38×24.7 |
25 |
38 |
24.7 |
51.5 |
47.4 |
0.085 |
||||||||||
|
K 40×48×20 |
40 |
48 |
20 |
33 |
51 |
0.052 |
||||||||||
|
Bearing Tpye |
Dimensions（mm） |
Rated load（kN） |
Weight (kg) |
|
||||||||||||
|
d |
Fw |
D |
B |
rs |
Cr |
Cor |
|
|||||||||
|
NKI 20/16 |
20 |
24 |
32 |
16 |
0.3 |
15.2 |
22.2 |
0.049 |
|
|||||||
|
NKI 20/20 |
20 |
24 |
32 |
20 |
0.3 |
19.2 |
30.2 |
0.061 |
|
|||||||
|
NKI 203316 |
20 |
24 |
33 |
16 |
0.3 |
15.2 |
22.2 |
0.051 |
|
|||||||
|
NKI 25/20 |
25 |
29 |
38 |
20 |
0.3 |
22.2 |
34 |
0.079 |
|
|||||||
|
NKI 25/30 |
25 |
29 |
38 |
30 |
0.3 |
33.5 |
58 |
0.124 |
|
|||||||
|
NKI 28/20 |
28 |
32 |
42 |
20 |
0.3 |
23.5 |
37.8 |
0.097 |
|
|||||||
|
NKI 28/30 |
28 |
32 |
42 |
30 |
0.3 |
35.5 |
64.2 |
0.146 |
|
|||||||
|
NKI 30/20 |
30 |
35 |
45 |
20 |
0.3 |
24.8 |
41.5 |
0.112 |
|
|||||||
|
NKI 30/30 |
30 |
35 |
45 |
30 |
0.3 |
37.5 |
70.5 |
0.17 |
|
|||||||
|
NKI 35/20 |
35 |
40 |
50 |
20 |
0.3 |
26.5 |
47.2 |
0.127 |
|
|||||||
|
NKI 35/30 |
35 |
40 |
50 |
30 |
0.3 |
40 |
80.2 |
0.193 |
|
|||||||
|
NKI 40/20 |
40 |
45 |
55 |
20 |
0.3 |
28 |
52.8 |
0.142 |
|
|||||||
|
NKI 40/30 |
40 |
45 |
55 |
30 |
0.3 |
42.5 |
89.8 |
0.216 |
|
|||||||
|
NKI 50/25 |
50 |
— |
68 |
25 |
0.6 |
40.2 |
88 |
0.27 |
|
|||||||
|
NK 24/16 |
— |
24 |
32 |
16 |
0.3 |
15.2 |
22.2 |
0.032 |
|
|||||||
|
NK 24/20 |
— |
24 |
32 |
20 |
0.3 |
19.2 |
30.2 |
0.04 |
|
|||||||
|
NK 25/16 |
— |
25 |
33 |
16 |
0.3 |
15.1 |
24.5 |
0.033 |
|
|||||||
|
NK 25/20 |
— |
25 |
33 |
20 |
0.3 |
19 |
32.5 |
0.042 |
|
|||||||
|
NK 26/16 |
— |
26 |
34 |
16 |
0.3 |
15.7 |
26 |
0.034 |
|
|||||||
|
NK 26/20 |
— |
26 |
34 |
20 |
0.3 |
19.4 |
34.5 |
0.042 |
|
|||||||
|
NK 28/20 |
— |
28 |
37 |
20 |
0.3 |
22 |
36.5 |
0.052 |
|
|||||||
|
NK 28/30 |
— |
28 |
37 |
30 |
0.3 |
31.9 |
60 |
0.082 |
|
|||||||
|
NK 29/20 |
— |
29 |
38 |
20 |
0.3 |
22.2 |
34 |
0.054 |
|
|||||||
|
NK 29/30 |
— |
29 |
38 |
30 |
0.3 |
33.5 |
58 |
0.084 |
|
|||||||
|
NK 30/20 |
— |
30 |
40 |
20 |
0.3 |
22.9 |
38 |
0.065 |
|
|||||||
|
NK 30/30 |
— |
30 |
40 |
30 |
0.3 |
33 |
63 |
0.098 |
|
|||||||
|
NK 32/20 |
— |
32 |
42 |
20 |
0.3 |
23.5 |
37.8 |
0.068 |
|
|||||||
|
NK 32/30 |
— |
32 |
42 |
30 |
0.3 |
35.5 |
64.2 |
0.102 |
|
|||||||
|
NK 35/20 |
— |
35 |
45 |
20 |
0.3 |
24.8 |
41.5 |
0.074 |
|
|||||||
|
NK 35/30 |
— |
35 |
45 |
30 |
0.3 |
37.8 |
70.5 |
0.112 |
|
|||||||
|
NK 40/20 |
— |
40 |
50 |
20 |
0.3 |
26.5 |
47.2 |
0.083 |
|
|||||||
|
NK 40/30 |
— |
40 |
50 |
30 |
0.3 |
40 |
80.2 |
0.125 |
|
|||||||
|
NK 45/20 |
— |
45 |
55 |
20 |
0.3 |
28 |
52.8 |
0.092 |
|
|||||||
|
NK 45/30 |
— |
45 |
55 |
30 |
0.3 |
42.5 |
89.8 |
0.139 |
|
|||||||
|
NK 50/25 |
— |
50 |
62 |
25 |
0.6 |
38 |
78 |
0.161 |
|
|||||||
|
NK 50/35 |
— |
50 |
62 |
35 |
0.6 |
49 |
110 |
0.221 |
|
|||||||
|
NK 70/25 |
— |
70 |
85 |
25 |
0.6 |
44.6 |
98 |
0.262 |
|
|||||||
|
NK 70/35 |
— |
70 |
85 |
35 |
0.6 |
63 |
144 |
0.372 |
|
|||||||
|
NK 122834 |
— |
12 |
28 |
34 |
0.6 |
31.8 |
38.6 |
0.123 |
|
|||||||
|
NK 123234 |
— |
12 |
32 |
34 |
0.6 |
31.8 |
38.6 |
0.173 |
|
|||||||
|
NK 405214 |
— |
40 |
52 |
14 |
0.6 |
24.2 |
34.5 |
0.071 |
|
|||||||
|
NK 506212 |
— |
50 |
62 |
12 |
0.6 |
18.5 |
32 |
0.079 |
|
|||||||
|
NK 506412 |
— |
50 |
64 |
12 |
0.6 |
18.5 |
32.1 |
0.098 |
|
|||||||
|
NK 506414 |
— |
50 |
64 |
14 |
0.6 |
26.5 |
41.5 |
0.108 |
|
|||||||
|
NA 4830 |
150 |
— |
190 |
40 |
1.1 |
147 |
415 |
2.73 |
|
|||||||
|
NA 4911 |
55 |
63 |
80 |
25 |
1.5 |
51.4 |
105 |
0.442 |
|
|||||||
|
NA 4914 |
70 |
80 |
100 |
30 |
1.5 |
84 |
156 |
0.811 |
|
|||||||
|
NAV 4004 |
20 |
— |
42 |
22 |
0.3 |
37.7 |
62.3 |
0.172 |
|
|||||||
|
NAV 4904 |
20 |
— |
37 |
17 |
0.3 |
39.4 |
46 |
0.103 |
|
|||||||
|
NAV 4905 |
25 |
— |
42 |
17 |
0.3 |
44 |
55.7 |
0.115 |
|
|||||||
|
NAV 4906 |
30 |
— |
47 |
17 |
0.3 |
48 |
65.3 |
0.131 |
|
|||||||
|
NAV 4907 |
35 |
— |
55 |
20 |
0.6 |
59.6 |
91.4 |
0.206 |
|
|||||||
|
RNAV 4006 |
— |
40.1 |
55 |
25 |
0.3 |
54.5 |
98.3 |
0.191 |
|
|||||||
|
RNAV 4904 |
— |
25 |
37 |
17 |
0.3 |
39.4 |
46 |
0.082 |
|
|||||||
|
RNAV 4905 |
— |
30 |
42 |
17 |
0.3 |
44 |
55.7 |
0.093 |
|
|||||||
|
RNAV 4906 |
— |
35 |
47 |
17 |
0.6 |
48 |
65.3 |
0.105 |
|
|||||||
|
RNAV 4907 |
— |
42 |
55 |
20 |
0.6 |
59.6 |
91.4 |
0.131 |
|
|||||||
